Grundfos Fußventil 2L-G5/8 PV/V,E/C U2 (98070968)
Produkt ID: 98070968
Anfrage Preis und Verfügbarkeit
Grundfos Fußventil 2L-G5/8 PV/V,E/C U2 (98070968)
Grundfos Fußventil 2L-G5/8 PV/V,E/C U2 (98070968)
Foot valves are installed at the lower end of the suction Hose and include weight, strainer (mesh size 0,8mm) and non-return valve Additionally they include
cylindrical tanks, or for use with tank adaptors.
|
| Technische Daten: | |
| Max. Durchfluss: | 60 l/h |
| Level indication: | Low level and empty tank |
| Werkstoffe: | |
| Werkstoff: | Plastic |
| Material: | PVDF |
| Ventilkugel: | Ceramic |
| Al2O3 | |
| Dichtung: | Elastomer |
| FKM/EPDM | |
| Cable jacket: | Plastic |
| PE | |
| Installation: | |
| Anschlusstyp: | Connection pack |
| Anschlussgröße: | 4/6, 6/9, 6/12, 9/12 |
| Elektrische Daten: | |
| Kabellänge: | 5 m |
| Steckertyp: | Rund |
| Plug size: | M12 |
| Sonstiges: | |
| Nettogewicht: | 0.48 kg |
| Bruttogewicht: | 0.48 kg |
| Versandvol.: | 0.005 m³ |
| Herkunftsland: | DE |
