Grundfos Lifting chain (98425807)
Produkt ID: 98425807
Anfrage Preis und Verfügbarkeit
Grundfos Lifting chain (98425807)
Grundfos Lifting chain (98425807)
This product is solely designed to lift and lower the pumps into water and wastewater segments.
The product consists of:
|
This product is certified and the equipment complies to the EU-Maschinenrichtlinie 2006/42/EU.
| Specification | Value |
|---|---|
| The safety standards followed: | EN 818-1 + A1 |
| Technische Daten: | |
| Zulassungen: | CE |
| Werkstoffe: | |
| Werkstoff: | Edelstahl |
| EN 1.4571 | |
| AISI 316Ti | |
| Sonstiges: | |
| Nettogewicht: | 59.5 kg |
| Bruttogewicht: | 92.6 kg |
| Versandvol.: | 0.317 m³ |
| Gesamtlänge: | 8000 mm |
| Chain thickness: | 16 mm |
| Rigg bottom opening width: | 39 mm |
| Number of masterlink: | 4 |
| Load certificate (Yes/No): | Ja |
| Maximum working load: | 3200 kg |
| Equipment standard: | EU-Maschinenrichtlinie 2006/42/EU |
| Safety standard lifting: | EN 818-1 + A1:2008 |
| Safety standard sling: | EN 1677:2000 |
