Grundfos MG90LC (86U15906)
Produkt ID: 86U15906
Anfrage Preis und Verfügbarkeit
Grundfos MG90LC (86U15906)
Grundfos MG90LC (86U15906)
| Installation: | |
| Umgebungstemperatur: | -30 .. 60 °C |
| Flanschgröße des Motors: | FT115 |
| Elektrische Daten: | |
| Std. Motor: | IEC |
| Bauart des Motors: | 90LC |
| Motorbemessungsleistung P2: | 1.5 kW |
| Netzfrequenz: | 50 Hz |
| Bemessungsspannung: | 3 x 380-415D V |
| Bemessungsstrom: | 3.55-3.65 A |
| Maximale Stromaufnahme: | 3.90-4.00 A |
| Anlaufstrom: | 730-790 % |
| Leistungsfaktor Cos phi: | 0.75-0.68 |
| Nenn-Drehzahl: | 1450-1460 1/min |
| Nenn-Drehmoment bei Vollast: | 9.9 Nm |
| Anlaufmoment: | 280 % |
| Kippmoment des Motors: | 330-350 % |
| Trägheitsmoment: | 0.0041 kg m² |
| Wirkungsgrad: | IE3 85,3% |
| IE-Wirkungsgradklasse: | IE3 |
| Motorwirkungsgrad bei Vollast: | 85.3 % |
| Motorwirkungsgrad bei 3/4-Last: | 85.8 % |
| Motorwirkungsgrad bei halber Last: | 84.2 % |
| Motorpole: | 4 |
| Schutzart (gemäß IEC 34-5): | 55 Dust/Jetting |
| Wärmeklasse (IEC 85): | F |
| Sonstiges: | |
| Nettogewicht: | 22 kg |
| Farbcode: | NCS 9000 glänzend 40 +/-10, Kataphoresebeschichtung |
