Grundfos MG90LB (85903279)
Produkt ID: 85903279
Anfrage Preis und Verfügbarkeit
Grundfos MG90LB (85903279)
Grundfos MG90LB (85903279)
1-phasiger Normmotor
| Installation: | |
| Umgebungstemperatur: | -30 .. 40 °C |
| Flanschgröße des Motors: | FT115 |
| Elektrische Daten: | |
| Std. Motor: | IEC |
| Bauart des Motors: | 90LB |
| Motorbemessungsleistung P2: | 1.5 kW |
| Netzfrequenz: | 50 Hz |
| Bemessungsspannung: | 1 x 110/220 V |
| Bemessungsstrom: | 20.0/10.0 A |
| Anlaufstrom: | 660 % |
| Leistungsfaktor Cos phi: | 0.99 |
| Nenn-Drehmoment bei Vollast: | 5.15 Nm |
| Anlaufmoment: | 60 % |
| Kippmoment des Motors: | 220 % |
| Trägheitsmoment: | 0.0029 kg m² |
| Motorwirkungsgrad bei Vollast: | 72 % |
| Motorpole: | 2 |
| Schutzart (gemäß IEC 34-5): | 55 Dust/Jetting |
| Wärmeklasse (IEC 85): | F |
| Sonstiges: | |
| Nettogewicht: | 19 kg |
| Farbcode: | NCS 9000 glänzend 40 +/-10, Kataphoresebeschichtung |
