Grundfos JPB 6 A-A-CVBP (4661BPBB)
Produkt ID: 4661BPBB
Anfrage Preis und Verfügbarkeit
Grundfos JPB 6 A-A-CVBP (4661BPBB)
Grundfos JPB 6 A-A-CVBP (4661BPBB)
| Specification | Value | |
|---|---|---|
| Liquid: | ||
| Pumped liquid: | Water | |
| Liquid temperature range: | 0 .. 40 °C | |
| Liquid temperature during operation: | 20 °C | |
| Density: | 998.2 kg/m³ | |
| Technical: | ||
| Primary shaft seal: | CVBP | |
| Approvals on nameplate: | CE,EAC | |
| Curve tolerance: | ISO9906:2012 3B | |
| Materials: | ||
| Pump housing: | Stainless steel | |
| EN 1.4301 | ||
| AISI 304 | ||
| Impeller: | Stainless steel | |
| DIN W.-Nr. 1.4301 | ||
| AISI 304 | ||
| Installation: | ||
| Range of ambient temperature: | 0 .. 40 °C | |
| Maximum operating pressure: | 6 bar | |
| Pump inlet: | EXT.G1 | |
| Pump outlet: | INT.RP1 | |
| Electrical data: | ||
| Power input - P1: | 1400 W | |
| Mains frequency: | 50 Hz | |
| Rated voltage: | 1 x 220-240 V | |
| Rated current: | 6 A | |
| Capacitor size - run: | 25 µF/400 V | |
| Enclosure class (IEC 34-5): | IP44 | |
| Insulation class (IEC 85): | F | |
| Length of cable: | 1.5 m | |
| Type of cable plug: | SCHUKO | |
| Tank: | ||
| Volume of pressure tank: | 24 l | |
| Others: | ||
| Net weight: | 23 kg | |
| Gross weight: | 25 kg | |
