Grundfos MSS.11.3.2 (97901063)
Produkt ID: 97901063
Anfrage Preis und Verfügbarkeit
Grundfos MSS.11.3.2 (97901063)
Grundfos MSS.11.3.2 (97901063)
| Specification | Value | |
|---|---|---|
| Technical: | ||
| Type of impeller: | VORTEX | |
| Maximum particle size: | 40 mm | |
| CE approved (Yes/No): | Y | |
| EN number for LGA approval: | Y | |
| Valve type: | NONE | |
| Materials: | ||
| Pump housing: | Composite | |
| Tank: | LDPE | |
| Gasket: | NBR | |
| Liquid: | ||
| Maximum liquid temperature: | 40 °C | |
| Density: | 998.2 kg/m³ | |
| Electrical data: | ||
| Power input - P1: | 1.8 kW | |
| Rated power - P2: | 1.1 kW | |
| Mains frequency: | 50 Hz | |
| Rated voltage: | 3 x 400 V | |
| Voltage tolerance: | +10/-6 % | |
| Max starts per. hour: | 60 | |
| Rated current: | 3.1 A | |
| Cos phi - power factor: | 0,85 | |
| Rated speed: | 2785 rpm | |
| Number of poles: | 2 | |
| Start. method: | direct-on-line | |
| Enclosure class (IEC 34-5): | IP68 | |
| Insulation class (IEC 85): | F | |
| Type of cable plug: | CEE3P+N+PE | |
| Mains cable: | 1.5 m | |
| Tank: | ||
| Total volume of tank(s): | 44 l | |
| Total effective volume of collecting tank at 180 mm inlet: | 20 l | |
| Total effective volume of collecting tank at 250 mm inlet: | 28 l | |
